| OPERATION CLASS |
D |
| NUMBER OF CHANNELS |
01 |
| MAXIMUM POWER |
Output Power @14.4VDC*
0.5 OHM: 8000W RMS
1 OHM: 8000W RMS
2 OHMS: 8000W RMS
4 OHMS: 4800W RMS |
| INPUT SENSITIVITY |
4V ~0.2V |
| SIGNAL TO NOISE RATIO |
>90dB |
| FREQUENCY RESPONSE |
8Hz ~ 200Hz (-3dB) |
| CROSSOVER HIGH PASS (HPF) |
8Hz ~ 30Hz (-12dB/8ª) Variable |
| CROSSOVER LOW PASS (LPF) |
60Hz ~ 200Hz (-12dB/8ª) Variable |
| BASS BOOST |
Freq.: 35Hz ~ 55Hz
Boost: 0 ~ +10dB |
| EFFICIENCY |
78% @ 0.5 Ohm | 82% @ 1 Ohm | 86% @ 2 Ohms |
| INPUT IMPEDANCE |
10K Ohms |
| OUTPUT IMPEDANCE |
0.5 Ohm ~ 2 Ohms |
| PROTECTION SYSTEM |
Output short-circuit, low/high supply voltage and
Thermal protection |
| MINIMUM SUPPLY VOLTAGE |
9VDC |
| MAXIMUM SUPPLY VOLTAGE |
17VDC |
| CONSUMPTION AT REST |
5.0A |
| MAXIMUM MUSIC CONSUMPTION |
356A @ 0.5 Ohm | 339A @ 1 Ohm | 323A @ 2 Ohms |
| MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL |
712A @ 0.5 Ohm | 678A @ 1 Ohm | 646A @ 2 Ohms |
| DIMENSIONS (WXHXD) |
9.37" x 2.80" x 20.16" (238 x 71 x 512mm) |
| WEIGHT |
16.39lb (7,45Kg) |
